We are Delkang Refrigeration Equipment, based in Xiangshui County. We have specialized in refrigeration equipment since 2006. Our water-cooled refrigeration condenser is a reliable solution for complex operating conditions.
It is compatible with various water types, including tap water, soft water, and high-hardness well water. For high-hardness applications, a professional descaling device can be added. We also use 316L stainless steel tubes to effectively prevent scaling and corrosion from the start, ensuring long-term reliability.
Proven Performance in Real Applications
This condenser is widely used in chemical cooling systems and large central air conditioning projects. Customers report low failure rates and minimal maintenance requirements over time.
Our factory covers 6,000 square meters and employs 30 workers. We maintain strict quality control at every stage of production to ensure consistent performance. OEM and ODM services are available, and we can manufacture customized units based on your drawings.
Key Specifications for Easy Selection
We offer flexible configurations to meet different project requirements, helping you choose the most suitable solution.
|
Parameter |
Value |
|
Cooling Water Inlet Temperature |
Typically 32°C (min. 25°C, max. 38°C) |
|
Water Pressure |
Inlet: 0.2–0.4 MPa; Outlet: 0.15–0.35 MPa |
|
Standard Flow Rate |
15–30 m³/h (for 50–100 m² heat exchange area) |
|
Suitable Water Quality |
Tap water or soft water with hardness ≤ 250 mg/L |
|
Shell/Tube Passes |
Typically 1 shell pass and 2 tube passes; up to 4 tube passes for large units |
|
Pressure Drop |
Water side ≤ 0.05 MPa; Refrigerant side ≤ 0.1 MPa |
Our goal is to provide durable equipment that is easy to maintain. You can rely on our water-cooled refrigeration condenser for stable, long-term operation.
