We are Delkang Refrigeration Equipment, based in Xiangshui County. We have been manufacturing refrigeration equipment since 2006. Our evaporative condensing unit combines the advantages of both water cooling and air cooling, delivering high efficiency with reduced water consumption.
This unit is designed for customers who require both strong performance and effective water savings.
Measurable Water Savings
Water consumption is controlled at 1.5–3.0 m³/(h·100 m² heat exchange area). A specially designed drift eliminator keeps water loss as low as ≤0.1%, significantly lower than the typical ≤0.3%.
This results in real cost savings on water usage. The unit is also equipped with automatic chemical and physical descaling systems, effectively preventing scale buildup and reducing maintenance requirements.
Designed for Year-Round Operation
For cold climates, an optional electric heating system can be added to ensure stable winter operation.
Our factory is equipped with a fully automatic tube bending line and a high-speed fin stamping line. We support third-party inspections and have proven performance in large power plants and chemical facilities.
Key Specifications
|
Parameter |
Value |
|
Water Consumption |
1.5–3.0 m³/(h·100 m² heat exchange area) |
|
Water System |
Make-up rate: 5%–8%; Blowdown rate: 3%–5% |
|
Water Drift Rate |
Standard: ≤0.3%; High-efficiency: ≤0.1% |
|
Pump Power |
1.5–7.5 kW |
|
Spray System |
Counter-flow (standard); Parallel flow (large units) |
|
Freeze Protection |
Electric heating: 2–5 kW (optional) |
|
Total Power |
10–50 kW (for 100–500 m² heat exchange area) |
Compared to traditional water-cooled condensers, this unit can reduce water consumption by over 60%. A one-year warranty is provided for your assurance.
