We are Delkang Refrigeration Equipment, based in Xiangshui County. Since 2006, we have specialized in manufacturing refrigeration equipment. Our U-type condenser is designed for demanding operating environments, offering a stable structure and excellent seismic resistance.
It is widely used in heavy industrial systems and marine cooling applications.
U-Shaped Structure for Enhanced Stability
The unit typically ranges from 0.8–2.0 m in diameter and 2–6 m in length. The standard connection configuration is end inlet and end outlet, with customization available to match specific system requirements.
Our factory is equipped with a professional R&D team dedicated to continuous product improvement. We operate a 6,000 square meter facility with 30 skilled workers.
Reliable Performance Under Harsh Conditions
The unit is designed to withstand pressures of ≥1.6 MPa and meets seismic resistance standards of grade 7 or higher. It performs reliably under ship motion and industrial vibration.
With 6–12 rows of fins and a face air velocity of 2.0–3.5 m/s, the condenser maintains stable heat exchange performance even in high-temperature and high-vibration environments.
OEM and ODM services are supported, and we can manufacture according to your drawings.
Key Specifications
|
Parameter |
Value |
|
Installation Size |
Diameter: 0.8–2.0 m × Length: 2–6 m |
|
Connection Type |
End inlet/outlet; customizable |
|
Structural Strength |
Pressure ≥1.6 MPa; Seismic grade ≥7 |
|
Fin Rows |
6–12 rows |
|
Face Air Velocity |
2.0–3.5 m/s |
|
Maintenance Space |
≥0.8 m required |
|
Maintenance Design |
Built-in cleaning port; supports online cleaning |
A built-in cleaning port enables easy maintenance without major disassembly. This U-type condenser has demonstrated long-term durability in marine vessels and petrochemical applications.
