We are Delkang Refrigeration Equipment, with more than 20 years of experience in refrigeration manufacturing. Our commercial air conditioning condenser is designed for shopping malls, office buildings, and other commercial facilities.
It is compatible with a wide range of commercial air conditioning compressors, making it a flexible solution for commercial cooling projects.
Wide Compatibility Range
The unit can be matched with screw compressors from 10–100 HP and scroll compressors from 5–50 HP. Cooling capacity ranges from 25–300 kW, covering most commercial air conditioning systems.
The standard power supply is 380V/50Hz three-phase, with 220V/50Hz single-phase available for smaller units.
Low Noise and Energy Efficiency
Indoor units operate at ≤60 dB, while outdoor units operate at ≤70 dB, ensuring a comfortable environment. The system meets high energy efficiency standards (Level 1 or above).
The fans operate together with the compressor, starting and stopping automatically while adjusting speed according to temperature, which helps reduce energy consumption.
Our factory covers 6,000 square meters and employs 30 workers. OEM and ODM services are available.
Key Specifications
|
Parameter |
Value |
|
Compressor Compatibility |
Screw: 10–100 HP; Scroll: 5–50 HP |
|
Cooling Capacity |
25–300 kW |
|
Voltage/Frequency |
380V/50Hz three-phase; Optional 220V/50Hz single-phase |
|
Equipment Size |
Length: 0.8–2.5 m × Width: 0.6–1.5 m × Height: 0.5–1.2 m |
|
Noise Level |
Indoor ≤60 dB; Outdoor ≤70 dB |
|
Energy Efficiency |
≥ Level 1 (commercial AC standard) |
|
Fan Control |
Automatic start/stop with compressor; Temperature-based speed control |
This commercial AC condenser offers reliable performance and energy savings for office buildings and shopping malls. A one-year warranty is included.
