We are Delkang Refrigeration Equipment, based in Xiangshui County. Since 2006, we have specialized in refrigeration equipment manufacturing. Our industrial condenser is designed for heavy-duty applications such as power plants and petrochemical facilities, where extremely large heat exchange capacity is required.
Flexible Capacity for Large Installations
We offer both single-unit and modular configurations. A single unit provides a heat exchange area of 500–2,000 m². In modular systems, each module provides 200–500 m² and can be combined to exceed 5,000 m². Customized systems can be designed with a total heat exchange area of up to 10,000 m².
Our industrial condenser can be expanded as your project grows.
High Pressure Strength and Reliable Construction
The unit is designed with a pressure rating of 1.6–4.0 MPa and a test pressure of 2.4–6.0 MPa. The shell uses steel plates with a thickness of 10–20 mm, and the tubes are 1.5–3.0 mm thick. Materials can be selected according to specific operating conditions.
Pressure testing is carried out section by section, with each section tested at 1.5 times the design pressure. Test reports and material certificates are provided. OEM and ODM services are supported.
Key Specifications
|
Parameter |
Value |
|
Heat Exchange Area |
Single unit: 500–2,000 m²; Modular systems: ≥5,000 m²; Custom up to 10,000 m² |
|
Pressure Rating |
Design: 1.6–4.0 MPa; Test: 2.4–6.0 MPa |
|
Material Thickness |
Shell: 10–20 mm; Tubes: 1.5–3.0 mm |
|
Fixed Structure |
Steel supports; M24–M48 anchor bolts; Lifting points ≥1.5× equipment weight |
|
Test Standard |
Section testing ≥1.5× design pressure |
This industrial condenser has demonstrated reliable performance in large coal chemical projects and power plants. A one-year warranty is provided.
